The Edelbrock Supercharger System part #1598 is for the 2010-13 Camaro SS with a MANUAL transmission. This kit produces 599 horsepower and 547 ft-lbs of torque.
The Edelbrock supercharger Stage 1 Street system part #1598 for 2010-2013, Manual Trans, Camaro SS increases the performance of your LS3 engine to 599 horsepower and 547 ft-lbs of torque at the crank. The core of this system is the Eaton Gen VI 2300 TVS rotating assembly with a four-lobe design with 160 degrees of twist for maximum flow, minimum temperature rise and quiet operation for excellent drivability. We also designed our superchargers with an integrated bypass valve to help eliminate parasitic loss under light throttle, improving mileage potential. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. The Edelbrock #1598 system is 50-state emissions legal. The supplied tune is intended for completely stock vehicles with the exception of a cat-back exhaust. 2010-15 convertible installations will require the use of Edelbrock Convertible Brace #15956 (sold separately).
Application Summary:
| Year |
Make/Model |
| 2010-2013 |
Chevrolet Camaro |
| Attributes |
| 9040 |
D-215-89 |
| Air Filter Included |
Yes |
| ASIN |
B003EP14OE |
| Calibration |
Yes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| CARB Executive Order Number |
D-215-89, D-215-89 |
| Center Housing Cooling Type |
Intercooler |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Finish |
Black Powder Coated, Black Powder Coated, Black Powder Coated |
| Fuel Injector Type |
52 |
| Gasket Or Seal Included |
Yes |
| Harmonic Balancer Diameter |
7.5 |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Hose Included |
Yes, Yes, Yes |
| Housing Material |
Cast Aluminum |
| Internal Step Up |
Yes |
| Life Cycle Status Code |
Available to Order |
| Maximum Boost Pressure |
7.5 |
| Maximum Horsepower |
599 |
| Maximum Pressure Reading |
7.5, 7.5, 7.5 |
| Maximum Torque |
547, 547, 547 |
| Mounting Bracket Included |
Yes, Yes, Yes |
| Mounting Hardware Included |
Yes, Yes, Yes |
| NAFTA Preference Criterion Code |
B |
| Oil Capacity |
150 |
| Outside Pulley Diameter |
3.5 |
| Potential Risk Chemical |
Chrome |
| Pulley Belt Width |
6-Rib |
| Quantity |
Kit |
| RGL |
WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Chromium, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Rotor Type |
Eaton TVS 2300, Eaton TVS 2300, Eaton TVS 2300 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| System Type |
Stage 1 - Street System |
| Tensioner Included |
Yes, Yes, Yes |
| Transmission Type |
Manual |
| Universal Or Specific Fit |
Specific |
| Vehicle Model |
Camaro, Camaro, Camaro |
| Warranty Time |
36 |
| GTIN |
00085347015986 |
