Edelbrock Victor Jr. LS1 Carbureted Intake Manifold Only For Chevrolet LS Gen III
Edelbrock part #29087 Victor Jr. LS1 intake manifold is a high-rise single-plane intake capable of supporting up to 600 hp. The Victor Jr. LS1 features a flange that accepts a square-bore carburetors. It can be used on LS2 applications when matched with MSD's #6012 LS2 ignition controller (available through MSD Performance). Includes a throttle bracket designed to work with 700R-4, 200R-4 and Turbo 350 transmissions. Most applications will require hood modification.
Application Summary:
| Year |
Make/Model |
| Chevrolet:Small-Block |
LC9:325 (5.3L) |
| Chevrolet:Small-Block |
LH8:325 (5.3L) |
| Chevrolet:Small-Block |
LMF:325 (5.3L) |
| Chevrolet:Small-Block |
LMG:325 (5.3L) |
| Chevrolet:Small-Block |
LY5:325 (5.3L) |
| Chevrolet:Small-Block |
Gen III LM7:325 (5.3L) |
| Chevrolet:Small-Block |
Gen III LR4:293 (4.8L) |
| Chevrolet:Small-Block |
Gen III LS1:346 (5.7L) |
| Chevrolet:Small-Block |
Gen III LS2:364 (6.0L) |
| Chevrolet:Small-Block |
Gen IV LMF:325 (5.3L) |
| Chevrolet:Small-Block |
Gen IV LY5:325 (5.3L) |
| Attributes |
| ASIN |
B000VDJPMK |
| Basic Operating RPM Range |
3500-7500 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Center Maximum Height |
4.950, 4.95, 4.950 |
| CNC Ported |
No, No, No |
| Country of Origin (Primary) |
US |
| Cylinder Head Type |
Standard |
| EGR Port |
No |
| Emission |
Without EGR |
| Emission Code |
Off Road |
| Engine Make/Size |
Chevy Small Block LS1 |
| Finish |
Satin, Satin, Satin |
| Flange Type |
4150 |
| Front Maximum Height |
4.950, 4.95 |
| Gasket Or Seal Included |
No |
| Grade Type |
Performance, Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8708998175 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum, Aluminum |
| NAFTA Preference Criterion Code |
B |
| Number Of Carbs |
One |
| Position |
N/A |
| Potential Risk Chemical |
Lead |
| Rear Maximum Height |
4.950, 4.95 |
| RGL |
WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov., WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range |
3500-7500 |
| SDR Required Flag |
N |
| SDS Sheet Number |
NA |
| Series |
Victor, Victor |
| Single Or Dual Plane Type |
Single Plane, Single Plane, Single |
| Usage |
Racing |
| Vehicle Model |
Chevrolet, Chevrolet |
| Warranty Time |
12 |
| GTIN |
00085347290871 |
