Hedman Hedders has been manufacturing quality headers in the USA since 1954, and they've been manufacturing headers for Chevy trucks for nearly as long. Each set uses mild steel, smooth flowing, CNC mandrel bent tubes, that are hand-welded to ensure each pair is identical to the next. Hedman's unique, gasketless ball and socket collector design allows your SB Chevy exhaust system to bolt up, even if it is not perfectly aligned with the header collectors.
This set is part of Hedman's ELITE® line of headers, which have stout 3/8 in. flanges, and thicker 14 gauge primary tubes. The heavy-duty construction of HEDMAN ELITE® Hedders makes them ideal for high-performance engines and tow vehicles, which produce higher exhaust temperatures.
ELITE® models have a MATTE-SILVER ceramic finish that can withstand temperatures up to 1400 degrees F. The coating looks great and increases exhaust speeds for improved exhaust scavenging, and reduced under hood temperatures.
These LONG-TUBE headers fit 1967-1991 2WD & 4WD Chevy/GMC 1/2 Ton and 3/4 ton trucks, Blazers and Suburbans (check the application listings for exact fitment) powered by a Small Block Chevy engine (without A.I.R. System). The smooth 1-5/8 in. tube design provides ample exhaust flow to let your truck's 283-400 SB Chevy engine breathe easy, and produce maximum horsepower and torque.
Each set includes a pair of gaskets, header flange bolts and collector bolts. No collector gasket is needed.
Hedman Hedders is so confident in the quality of its headers that these headers are factory backed by a Limited Lifetime Warranty. The ceramic-metallic finish is covered by a 5-year factory warranty, in addition to Hedman's standard lifetime header warranty.
- Heavy-Duty ELITE Header Construction With Thick 3/8 in. Flanges and 14g Primary Tubes To Hold Up To The Added Tortures Of High-Performance and Truck Engines.
- Thermal Coating Keeps More Heat In The Headers To Keep Underhood Temps Down and Protect Against Corrosion.
- Ball & Socket Collector Design requires No Gasket, and Allows For More Exhaust System Misalignment than Old School, Gasket-Style Header Collectors
- Includes All The Necessary Mounting Hardware, Gaskets and Reducers (exhaust adapters)
- Limted Lifetime Warranty On Construction, Five Year Warranty on Factory-Applied Header Coating!
- Proud To Say, Made In The USA, Since 1954!
Application Summary:
| Year | Make/Model |
|---|---|
| 1976-1980 | Chevrolet C10 |
| 1967-1969 | Chevrolet C10 Pickup |
| 1967 | Chevrolet C10 Suburban |
| 1976-1980 | Chevrolet C20 |
| 1967-1969 | Chevrolet C20 Pickup |
| 1967 | Chevrolet C20 Suburban |
| 1976-1980 | Chevrolet C20 Suburban |
| 1976-1978 | Chevrolet C30 |
| 1967-1969 | Chevrolet C30 Pickup |
| 1975-1980 | Chevrolet K10 |
| 1967 | Chevrolet K10 Pickup |
| 1967 | Chevrolet K10 Suburban |
| 1975-1979 | Chevrolet K10 Suburban |
| 1975-1980 | Chevrolet K20 |
| 1967 | Chevrolet K20 Pickup |
| 1967 | Chevrolet K20 Suburban |
| 1975-1980 | Chevrolet K20 Suburban |
| 1975-1979 | Chevrolet K5 Blazer |
| 1976 | GMC C15 |
| 1978 | GMC C15 |
| 1967-1968 | GMC C15/C1500 Pickup |
| 1967 | GMC C15/C1500 Suburban |
| 1979-1980 | GMC C1500 |
| 1976-1978 | GMC C25 |
| 1978 | GMC C25 Suburban |
| 1967-1968 | GMC C25/C2500 Pickup |
| 1967 | GMC C25/C2500 Suburban |
| 1979 | GMC C2500 |
| 1980 | GMC C2500 Suburban |
| 1976-1978 | GMC C35 |
| 1967-1968 | GMC C35/C3500 Pickup |
| 1979 | GMC C3500 |
| 1975-1979 | GMC Jimmy |
| 1975-1978 | GMC K15 |
| 1975-1978 | GMC K15 Suburban |
| 1967 | GMC K15/K1500 Pickup |
| 1967 | GMC K15/K1500 Suburban |
| 1979-1980 | GMC K1500 |
| 1979-1980 | GMC K1500 Suburban |
| 1975-1978 | GMC K25 |
| 1975-1978 | GMC K25 Suburban |
| 1967 | GMC K25/K2500 Pickup |
| 1967 | GMC K25/K2500 Suburban |
| 1979-1980 | GMC K2500 |
| 1979-1980 | GMC K2500 Suburban |
| Attributes | |
| Air Conditioning | Yes, Yes, Yes |
| Application | Automotive |
| ASIN | B000COD3PS |
| Automatic Transmission - Column | Yes, Yes, Yes |
| Automatic Transmission - Floor | Yes, Yes, Yes |
| Bolts/Studs Included | Yes, Yes, Yes |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Catalytic Converter(s) Included | No, No, No |
| Chassis Compatibility | NOT For Vehicles With Offset (right) Engine Position!, NOT For Vehicles With Offset (right) Engine Position! |
| Coating/Finish | Metallic Ceramic |
| Collector Attachment | 3", 3 in., 3 in. |
| Collector Bolts Included | Yes, Yes, Yes |
| Collector Diameter | 3 in., 3 in. |
| Collector Size | 3", 3 in., 3 in. |
| Collector Style | Ball and Socket Style (Gasketless), BALL and SOCKET Style (Gasketless), BALL and SOCKET Style (Gasketless) |
| Collector Tube Size (in.) | 3 |
| Contents | headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, headers, gaskets (when applicable), 3-bolt exhaust adapters, hardware, One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware |
| Country of Origin (Primary) | US |
| Crossover Pipe Included | NO, No, No |
| Cylinder Head | Fits Factory GM Aluminum or Cast Iron, Angle Plug and Straight Plug Heads., Fits Factory GM Aluminum Angle Plug and Straight Plug Heads., Fits Factory GM Aluminum Angle Plug and Straight Plug Heads. |
| Cylinder Head Port Shape | Oval, Oval, Oval |
| Drivetrain | 2WD |
| E.O. # | No, No |
| Emission Code | Not in CA |
| Emissions Notes | NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only., NOT LEGAL FOR STREET USE ON '75-LATER MODEL YEARS! Legal for off-road use only., Not Legal For Street Use on '75-Later Model Years! Legal for off-road use only. |
| Engine Make/Size | Chevy Small Block (262-400) |
| Exhaust System Dia | 2-1/2", 2-1/2 in., 2-1/2 in. |
| Finish | Matte Silver Ceramic-Metallic, Matte Silver Ceramic-Metallic |
| Finish Type | MATTE SILVER Ceramic-metallic coated, MATTE SILVER Ceramic-metallic coated, MATTE SILVER Ceramic-metallic coated |
| Flange Style | Standard, Standard, Standard |
| FLANGE Thickness | 0.375", 0.375 in., 0.375 in. |
| Gasket # | 27520 |
| Gasket Or Seal Included | Yes, Yes, Yes |
| Harmonized Tariff Code (Schedule B) | 8708925000 |
| Hazardous Material Code | N |
| Head Flange Gasket | 27520 |
| Header Construction | ELITE Heavy-Duty, MILD STEEL- ELITE Heavy-Duty, MILD STEEL- ELITE Heavy-Duty |
| Header Fasteners Included | Yes, Yes |
| Header Finish | Matte Silver Ceramic-Metallic, Matte Silver Ceramic-Metallic, Matte Silver Ceramic-Metallic |
| Header Material | Mild Steel, Mild Steel, Mild Steel |
| Header Port Shape | Oval Port, Oval Port, Oval Port |
| Header Style | Long Tube, Long Tube |
| Installation Hardware Included | Yes, Yes, Yes |
| Life Cycle Status Code | Available to Order |
| Manual Transmission - Column | No, No, No |
| Manual Transmission - Floor | Yes, Yes, Yes |
| Material | Mild Steel, Mild Steel |
| Motor Mounts (Included) | NO, No |
| Motor Mounts Included | NO, No, No |
| Mounting Hardware Included | Yes, Yes, Yes |
| NAFTA Preference Criterion Code | B |
| Notes | 67-82 GM Full Size Blazer, Jimmy 283-400 w/A.I.R., 67-82 GM Full Size Blazer, Jimmy 283-400 w/A.I.R., 67-82 GM Full Size Blazer, Jimmy 283-400 w/A.I.R. |
| Package Contents | One pair of headers, head flange gaskets, collector flange gaskets (when applicable), 3-bolt exhaust adapters, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware, Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware |
| Port Shape | Oval, Oval, Oval |
| Power Steering | Yes, Yes, Yes |
| Primary Tube Diameter (in) | 1.625", 1.625 in., 1.625 in. |
| Primary Tube Gauge | 14g, 14g, 14g |
| Quantity | Sold as a pair., Sold as a pair., Sold as a pair. |
| Reducer Outlet Size | 2-1/2", 2-1/2 in., 2-1/2 in. |
| Reducers Included | Yes, Yes, Yes |
| Replacement Gasket | 27520, 27520, 27520 |
| Replacement Head Flange Gasket | 27520, 27520 |
| SDR Required Flag | N |
| Transmission Compatibility | may encounter clutch interference if cross shaft behind driver side rear port, may encounter clutch interference if cross shaft behind driver side rear port |
| Transmission Mount Included | NO |
| Transmission Mount/Crossmember (Included) | No, No |
| Transmission Mount/Crossmember Included | No |
| Transmission Notes | May encounter clutch shaft interference. If so, use 69092, 69093 or 69892, May encounter clutch shaft interference. If so, use 69092, 69093 or 69892, May encounter clutch shaft interference. If so, use 69092, 69093 or 69892 |
| Tube Design | LONG TUBE, LONG TUBES, Standard |
| Tube Diameter | 1-5/8 in., 1-5/8" |
| Tube Direction | Down Swept |
| Tube Length | LONG Tubes, Long Tubes, Long Tubes |
| Tube Material Thickness | 14g, 14g, 14g |
| Tube Size | 1.625, 1-5/8", 1-5/8 in., 1-5/8 in. |
| Tube Style | Long Tube, Long Tubes, Long Tubes |
| Tuned | NO, No, No |
| Variations | 69096, 69890, 69096, 69890, 69096, 69890 |
| Weld-Up | No, No, No |
| with A.I.R. | Yes |
| with A.I.R. System | No, No, No |
| with EGR | No, No, No |
| Y-Pipe Included | No, No, No |
| GTIN | 00732611698900 |
