PERTRONIX FLAME-THROWER III COIL. 45,000-VOLT RATED WITH 0.32-OHMS OF RESISTANCE. THIS COIL IS SPECIFICALLY ENGINEERED FOR IGNITOR III APPLICATIONS. BLACK OIL FILLED CANISTER STYLE.
Flame Thrower III coils feature an ultra low resistance and are designed specifically for the Ignitor III Electronic Ignition Conversion kits. They feature a high turn ratio and ultra-low primary resistance enabling the ignition system to charge faster at high RPM's.
Flame Thrower III coils feature an ultra low resistance and are designed specifically for the Ignitor III Electronic Ignition Conversion kits. They feature a high turn ratio and ultra-low primary resistance enabling the ignition system to charge faster at high RPM's.
- 45,000 volts.
- Ultra Low 0.32 primary resistance.
- Compatible with the Ignitor III and most capacitive discharge boxes.
- Charges to peak current typically 30-70% faster than other coils.
- Rapid charge time means maximum spark energy is sustained to higher engine RPM.
Information:
The Flame-Thrower canister style coil has been engineered to complement our Ignitor Electronic Ignition Conversion Kits and Plug n’ Play Distributors. Choose from the Flame-Thrower, Flame-Thrower II, and the Flame-Thrower III depending upon system voltage and resistance. Oil filled coils offer great heat control for street driven vehicles, while epoxy filled coils provide superior winding support for high vibration environments in off-road vehicles and boats.| Attributes | |
| ASIN | B002Q363XM |
| Attribute Data | 1 |
| Ballast Resistor Included | No |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Coil Internal Construction | Oil-Filled |
| Coil Shape | Round |
| Coil Type | Remote Mount Canister, Yes |
| Coil Wire Attachment | Female/Socket |
| Coil Wire Included | No |
| Color | Black, Black |
| Country of Origin (Primary) | CN |
| Emission Code | Legal US |
| Emission Description | This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the appropriate vehicle per the Manufacturer’s Application Guide and Installation Instructions. |
| EmissionFullDES | 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions., 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions. |
| Finish | Semi-Gloss |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Ignition Type | Electronic |
| Life Cycle Status Code | Available to Order |
| Maximum Diameter | 2.15 |
| Maximum Voltage | 45000 |
| Mount Type | Circular Bracket |
| Mounting Bracket Included | No |
| Mounting Hardware Included | No |
| Mounting Position | Vertical |
| NAFTA Preference Criterion Code | B |
| Overall Height | 6 |
| Primary Inductance | 2.5 |
| Primary Resistance | 0.32 |
| Requires External Resistor | No |
| SDR Required Flag | N |
| Secondary Resistance | 7000 |
| Title (Custom) | PerTronix 44011 Flame-Thrower III Coil 45,000 Volt 0.32 ohm Black |
| Turns Ratio | 110:1 |
| Voltage | 12 |
| Warranty Time | 90 |
| GTIN | 00694342531843 |
