PERTRONIX FLAME-THROWER HC COIL. 60,000-VOLT RATED WITH 0.32-OHMS. SPECIFICALLY ENGINEERED FOR IGNITOR III APPLICATIONS. E-CORE STYLE.
HC (High Current) E-core coils are engineered specifically for our Ignitor III Electronic Ignition Conversion kit. HC coils have a high turn ratio and ultra-low primary resistance enabling the ignition system to charge faster at high RPM's.
HC (High Current) E-core coils are engineered specifically for our Ignitor III Electronic Ignition Conversion kit. HC coils have a high turn ratio and ultra-low primary resistance enabling the ignition system to charge faster at high RPM's.
- 60,000 volts.
- Highly efficient E-core design.
- Vacuum potted coil body for longer life and increased reliability.
- 6063 T5 aluminum heat sink with black anodized corrosion resistant finish.
- Precision machined male high tension terminal and brass primary terminals.
Information:
High Power, High Current, High Voltage, PerTronix E-Core coils are designed for use with our Digital HP Ignition boxes.| Attributes | |
| ASIN | B002Q2PKNM |
| Attribute Data | 1 |
| Ballast Resistor Included | No |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Coil Internal Construction | Epoxy |
| Coil Shape | Square |
| Coil Type | Remote Mount E-Core, No |
| Coil Wire Attachment | Male/HEI |
| Coil Wire Included | No |
| Color | Black |
| Country of Origin (Primary) | MX |
| Emission Code | Legal US |
| Emission Description | This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the appropriate vehicle per the Manufacturer’s Application Guide and Installation Instructions. |
| EmissionFullDES | 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions., 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions. |
| Finish | Semi-Gloss /Matte |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Ignition Type | Electronic |
| Length | 4.6 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 60000 |
| Mount Type | Integrated Bracket |
| Mounting Bracket Included | Yes |
| Mounting Hardware Included | Yes |
| Mounting Position | Horizontal, Vertical |
| NAFTA Preference Criterion Code | B |
| Overall Height | 3.15 |
| Primary Inductance | 2.5, 2.5 |
| Primary Resistance | 0.32 |
| Requires External Resistor | No |
| SDR Required Flag | N |
| Secondary Resistance | 7000 |
| Title (Custom) | PerTronix 60103 Flame-Thrower HC Coil 60,000 Volt E-Core 0.32 ohm |
| Turns Ratio | 110:1, 110:1 |
| Voltage | 12, 12 |
| Warranty Time | 90 |
| Width | 4.65 |
| GTIN | 00694342520489 |
