PERTRONIX FLAME-THROWER HV COIL. 60,000-VOLT RATED WITH 0.45-OHMS. SPECIFICALLY ENGINEERED FOR IGNITOR II APPLICATIONS. E-CORE STYLE.
HV (High Voltage) E-core design yields an incredible 60,000 volts and operates with no degradation throughout temperature ranges that surpass military specifications. The special heat sink design efficiently transfer heat optimizing energy output for street/strip and off-road applications.
HV (High Voltage) E-core design yields an incredible 60,000 volts and operates with no degradation throughout temperature ranges that surpass military specifications. The special heat sink design efficiently transfer heat optimizing energy output for street/strip and off-road applications.
- 60,000 volts.
- Highly efficient E-core design.
- Vacuum potted coil body for longer life and increased reliability.
- 6063 T5 aluminum heat sink with black anodized corrosion resistant finish.
- Precision machined male high tension terminal and brass primary terminals.
Information:
High Power, High Current, High Voltage, PerTronix E-Core coils are designed for use with our Digital HP Ignition boxes.| Attributes | |
| ASIN | B001CMQLM6 |
| Attribute Data | 1 |
| Ballast Resistor Included | No |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Coil Internal Construction | Epoxy |
| Coil Shape | Square |
| Coil Type | Remote Mount E-Core, No |
| Coil Wire Attachment | Male/HEI |
| Coil Wire Included | No |
| Color | Black |
| Country of Origin (Primary) | MX |
| Emission Code | Legal US |
| Emission Description | This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the appropriate vehicle per the Manufacturer’s Application Guide and Installation Instructions. |
| EmissionFullDES | 1 - This product has been granted a California Air Resources Board (CARB) Executive Order (EO Number) Exemption. It is 50 State Legal when installed on the Specified vehicle per the Manufacturer’s Current Application Guide, the CARB EO, and Installation Instructions. |
| Finish | Semi-Gloss /Matte |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Ignition Type | Electronic |
| Length | 4.6 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 60000 |
| Mount Type | Integrated Bracket |
| Mounting Bracket Included | Yes |
| Mounting Hardware Included | Yes |
| Mounting Position | Horizontal, Vertical |
| NAFTA Preference Criterion Code | B |
| Overall Height | 3.15 |
| Primary Inductance | 3.8, 3.8 |
| Primary Resistance | 0.45 |
| Requires External Resistor | No |
| SDR Required Flag | N |
| Secondary Resistance | 7300 |
| Title (Custom) | PerTronix 60104 Flame-Thrower HV Coil 60,000 Volt E-Core 0.45 ohm |
| Turns Ratio | 90:1, 90:1 |
| Voltage | 12, 12 |
| Warranty Time | 90 |
| Width | 4.65 |
| GTIN | 00694342015527 |
